MSI Z790 GAMING PLUS WIFI Motherboard | Power, Performance & Versatility for Intel’s Latest CPUs
MSI Z790 GAMING PLUS WIFI Motherboard | Power, Performance & Versatility for Intel’s Latest CPUs
Couldn't load pickup availability
Built to support Intel's 14th, 13th, and 12th Gen processors, the MSI Z790 GAMING PLUS WIFI motherboard delivers exceptional performance, ultra-fast connectivity, and next-generation features for gamers, creators, and power users alike. With DDR5 memory support, PCIe 5.0, Wi-Fi 6E, and robust cooling options, this ATX motherboard is the perfect foundation for high-performance desktop builds.
Performance
Equipped with the Intel Z790 chipset and LGA1700 socket, the Z790 GAMING PLUS WIFI supports up to Intel® Core™ 14th Gen CPUs. The advanced memory architecture allows up to 256GB DDR5 RAM with overclocking speeds reaching 7200+ MHz. Its optimized DIMM slots support Intel® XMP 3.0 profiles for easy high-speed tuning, while PCIe 5.0 on the primary x16 slot ensures future-proof graphics performance.
Four M.2 slots—one from the CPU and three from the chipset—provide high-speed NVMe SSD support, including RAID capabilities for both SATA and NVMe configurations.
Connectivity
This motherboard is ready for ultra-fast data transfers with a comprehensive range of USB ports, including one USB 20Gbps Type-C, one USB 10Gbps Type-A, and six USB 5Gbps Type-A connectors, alongside eight USB 2.0 ports for peripherals. Intel® 2.5Gbps LAN and built-in Intel® Wi-Fi 6E with Bluetooth® 5.3 ensure low-latency wired and wireless networking, ideal for online gaming, streaming, and productivity.
Visual Output & Audio
Onboard HDMI 2.1 and DisplayPort 1.4 deliver crisp 4K resolution at 60Hz when using CPUs with integrated graphics. Audio is handled by the Realtek® ALC897 7.1-channel codec for immersive surround sound, enhanced further by optical S/PDIF output for external sound systems.
Design & Expansion
The ATX layout offers extensive expansion with four PCIe slots (1x PCIe 5.0 x16, 1x PCIe 4.0 x4, and two PCIe 3.0 x1). Six system fan headers, a pump fan connector, and multiple RGB headers provide excellent airflow and lighting customization. The inclusion of 4x EZ Debug LEDs aids in quick troubleshooting during builds or upgrades.
Specifications Table
| Feature | Details |
|---|---|
| Chipset | Intel Z790 |
| CPU Support | Intel® 14th/13th/12th Gen, Pentium® Gold, Celeron® |
| Socket | LGA1700 |
| Form Factor | ATX (243.84mm x 304.8mm) |
| Memory | 4x DDR5, up to 256GB, 7200+ MHz (OC) |
| Graphics Outputs | 1x HDMI 2.1, 1x DisplayPort 1.4 |
| Audio | Realtek® ALC897, 7.1-channel HD, S/PDIF out |
| Expansion Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x4, 2x PCIe 3.0 x1 |
| Storage | 4x M.2 (PCIe 4.0 x4 / SATA), 6x SATA 6Gb/s |
| RAID Support | RAID 0/1/5/10 for SATA & M.2 |
| USB Ports | 1x USB 20Gbps Type-C, 1x USB 10Gbps Type-A, 6x USB 5Gbps Type-A, 8x USB 2.0 |
| LAN | Intel® 2.5GbE LAN |
| Wireless | Intel® Wi-Fi 6E, Bluetooth® 5.3 |
| Cooling Headers | 1x CPU Fan, 1x Pump Fan, 6x System Fan |
| RGB Support | 2x ARGB (JARGB_V2), 2x RGB (JRGB) |
| Operating System Support | Windows® 11/10 64-bit |
| Debug Tools | 4x EZ Debug LED |
| BIOS Feature | Flash BIOS Button |
Application Scenarios
The Z790 GAMING PLUS WIFI is ideal for high-end gaming PCs, workstation builds, and enthusiast-level desktops requiring cutting-edge features, multi-GPU capabilities, and exceptional networking.
Why Choose the MSI Z790 GAMING PLUS WIFI?
With advanced support for DDR5, PCIe 5.0, and four M.2 slots, this motherboard delivers both speed and flexibility. The integrated Wi-Fi 6E and Bluetooth® 5.3 offer excellent wireless performance, while rich connectivity options future-proof your system for years. It’s the ideal pick for gamers and creators looking for performance without compromise.
Buy Now from Mustafa Computers
Level up your desktop with the MSI Z790 GAMING PLUS WIFI motherboard—now available at Mustafa Computers. Get reliable delivery and expert support when you shop with us.
