Thermalright SP-850 850W 80 PLUS Platinum Full-Modular Power Supply | 850W PSU | 120mm Fan | OPP/OVP/OTP/OCP/SCP/UVP
Thermalright SP-850 850W 80 PLUS Platinum Full-Modular Power Supply | 850W PSU | 120mm Fan | OPP/OVP/OTP/OCP/SCP/UVP
Couldn't load pickup availability
The Thermalright SP-850 is an 850W full-modular power supply designed for desktop PC systems requiring high-capacity and efficient power delivery. It features 80 PLUS Platinum efficiency, a 120mm cooling fan, and a compact power supply design.
With support for 100–240VAC input voltage and a comprehensive set of protection mechanisms, the SP-850 is designed for gaming PCs, workstations, and custom high-performance desktop systems.
Key Features
850W Power Output
The SP-850 delivers 850W of rated power, providing a high-capacity power solution for compatible desktop PC configurations.
80 PLUS Platinum Efficiency
The power supply is rated 80 PLUS Platinum, offering high energy efficiency during operation.
Full-Modular Design
The full-modular design allows the required power cables to be connected according to the system configuration, helping maintain a cleaner internal PC build.
120mm Cooling Fan
The SP-850 is equipped with a 120mm cooling fan for active thermal management during operation.
Multiple Protection Systems
The SP-850 includes:
- OPP — Over Power Protection
- OVP — Over Voltage Protection
- OTP — Over Temperature Protection
- OCP — Over Current Protection
- SCP — Short Circuit Protection
- UVP — Under Voltage Protection
Black & White Design
The SP-850 features a Black & White design, making it suitable for coordinated black-and-white PC builds.
Technical Specifications
| Specification | Details |
|---|---|
| Product | Thermalright SP-850 |
| Power Output | 850W |
| Efficiency | 80 PLUS Platinum |
| Modular Design | Full-Modular |
| Color | Black & White |
| Dimensions | L150 × W140 × H85 mm ±2 mm |
| Input Voltage | 100–240VAC |
| Input Current | 11–5.5A |
| Input Frequency | 47–63Hz |
| Fan Size | 120mm |
| Operating Temperature | 0–40°C |
| MTBF | >100,000 Hours |
| Protections | OPP / OVP / OTP / OCP / SCP / UVP |
| Warranty | 2 Years |
Cooling & Reliability
The SP-850 uses a 120mm cooling fan and is specified for an operating temperature range of 0–40°C.
The power supply has a manufacturer-rated MTBF of more than 100,000 hours.
Power Protection
The built-in protection system includes:
OPP / OVP / OTP / OCP / SCP / UVP
These provide protection against over-power, over-voltage, over-temperature, over-current, short-circuit and under-voltage conditions.
Ideal For
- Gaming PCs
- High-performance desktop systems
- Custom PC builds
- Workstations
- Black-and-white PC builds
- Full-modular PC configurations
- Systems requiring an 850W power supply
Warranty
2 YEARS WARRANTY
The Thermalright SP-850 comes with a 2-year warranty as specified by the manufacturer.
