UGREEN 85489 Revodok Pro 14-in-1 USB-C Docking Station | Triple 4K Display | Dual 8K DisplayPort | 100W PD | 10Gbps USB | 170MB/s SD/TF | Gigabit Ethernet

The UGREEN 85489 Revodok Pro 14-in-1 USB-C Docking Station is a professional laptop docking solution designed to expand a compatible USB-C laptop into a complete workstation. It combines triple-display connectivity, high-speed USB ports, 100W laptop charging, SD/TF card readers, Gigabit Ethernet and 3.5mm audio into a single docking station.

Featuring two DisplayPort outputs and one HDMI port, the UGREEN 85489 can support up to three 4K displays simultaneously on compatible Windows systems. Each DisplayPort can also support up to 8K@30Hz or 4K@120Hz when used for a single display with a compatible host device.

The dock is powered by the included 140W power adapter and provides up to 100W Power Delivery to a compatible laptop, while the dedicated USB-C charging port supports up to 27W for compatible mobile devices.

Key Features

14-in-1 Professional Connectivity

The UGREEN 85489 provides a comprehensive selection of ports for professional and hybrid-work environments:

• 2 × DisplayPort
• 1 × HDMI
• 1 × USB-C upstream port
• 1 × USB-C PD output up to 27W
• 2 × USB-C 10Gbps data ports
• 2 × USB-A 10Gbps data ports
• 1 × SD card slot
• 1 × TF/microSD card slot
• 1 × Gigabit Ethernet port
• 1 × 3.5mm AUX audio port
• 1 × DC power input

Triple 4K Display Support

Connect up to three 4K monitors simultaneously through the two DisplayPort outputs and HDMI port, providing an expanded workspace for multitasking, office applications, content creation and professional workflows.

For single-display operation, the DisplayPort outputs support up to:

• 8K@30Hz
• 4K@120Hz

8K@30Hz and 4K@120Hz operation requires a compatible laptop with DisplayPort 1.4 and DSC support.

For 4K@120Hz DisplayPort operation, UGREEN recommends using a DisplayPort 1.4 cable no longer than 3 metres.

100W Laptop Power Delivery

The UGREEN 85489 supports up to 100W Power Delivery for a compatible laptop, allowing users to charge their notebook while connecting displays, storage devices, networking equipment and other peripherals through the dock.

A dedicated 27W USB-C PD output is also available for charging compatible smartphones and tablets.

The 100W upstream laptop port and 27W USB-C output share a combined 100W power budget, so the maximum available power can be reduced when both ports are being used simultaneously.

High-Speed 10Gbps USB Connectivity

The dock provides four high-speed USB data ports:

• 2 × USB-C 10Gbps
• 2 × USB-A 10Gbps

These ports are designed for high-speed data transfer with compatible USB devices.

The supplied specifications indicate that a 20GB file can be transferred in approximately 32 seconds under suitable conditions.

The front USB-C ports are data-only and do not support charging or display output.

170MB/s SD & TF Card Readers

Built-in SD and TF/microSD card slots provide convenient access to memory cards without requiring an additional card reader.

Transfer speeds of up to 170MB/s are supported with compatible cards and equipment.

This makes the dock particularly useful for photographers, videographers and users who frequently transfer large media files.

Gigabit Ethernet

The integrated Gigabit Ethernet port provides a stable wired network connection for compatible laptops.

It is suitable for office networking, video conferencing, cloud backups and other network-intensive applications.

3.5mm Audio

A dedicated 3.5mm AUX audio port provides convenient connectivity for compatible headphones, speakers and other audio equipment.

USB-C, USB4 & Thunderbolt Compatibility

The UGREEN 85489 supports modern USB-C connectivity and is compatible with systems using:

• USB-C
• USB4
• Thunderbolt 3
• Thunderbolt 4
• Thunderbolt 5

For full functionality, the host laptop's USB-C port must support Power Delivery and DisplayPort Alt Mode.

Technical Specifications

Specification	Details
Brand	UGREEN
SKU	85489
Model Number	CM843-85489
Product Series	Revodok Pro
Product Type	USB-C Docking Station
Number of Ports	14
Hardware Interface	USB 3.2 Gen 2
Laptop Charging	Up to 100W
USB-C PD Output	Up to 27W
Power Adapter	140W
DisplayPort	2 × DisplayPort
DisplayPort Maximum	Up to 8K@30Hz / 4K@120Hz
HDMI	1 × HDMI
Display Support	Up to Triple 4K on compatible systems
USB-C Data	2 × USB-C, up to 10Gbps
USB-A Data	2 × USB-A, up to 10Gbps
SD Card	Up to 170MB/s
TF/microSD	Up to 170MB/s
Ethernet	Gigabit Ethernet
Audio	3.5mm AUX
Upstream Connection	USB-C
USB-C Compatibility	USB-C / USB4
Thunderbolt Compatibility	Thunderbolt 3 / 4 / 5
Supported Windows	Windows 10 / Windows 11
Power Input	140W DC
Cable Included	USB-C to USB-C, 1m
Power Adapter Included	140W
Power Cord	Includes UK plug
Manufacturer	Ugreen Group Limited

Display Specifications

The UGREEN 85489 is designed for high-resolution multi-monitor workstation setups.

Single Display

• DisplayPort: up to 8K@30Hz
• DisplayPort: up to 4K@120Hz
• HDMI: up to 4K

For 8K@30Hz or 4K@120Hz through DisplayPort, the host system must support DP 1.4 with DSC.

Triple Display

The dock can drive up to three 4K monitors simultaneously on compatible Windows systems using its dual DisplayPort and HDMI outputs.

Actual display configurations and maximum resolutions depend on the capabilities of the connected laptop.

Charging & Power

The included 140W power adapter supplies external power to the docking station.

The dock provides:

• Up to 100W laptop charging
• Up to 27W USB-C PD charging
• 100W combined power sharing between the upstream USB-C and 27W USB-C PD output
• PD 3.0 support required for 100W laptop charging

If a laptop requires more than 100W, the laptop's original power adapter should be used.

The 27W USB-C port is intended for charging only.

Compatibility

The UGREEN 85489 is suitable for compatible:

• Dell laptops
• HP laptops
• Windows laptops
• USB-C laptops
• USB4 laptops
• Thunderbolt 3 systems
• Thunderbolt 4 systems
• Thunderbolt 5 systems

The host USB-C port must support the required DisplayPort Alt Mode and Power Delivery functions for display and charging capabilities.

macOS Compatibility Note

The supplied specifications state that the dock is not recommended for MacBook users who require multiple external monitors displaying different content.

On macOS, connected external displays will display identical content according to the supplied product information.

Users should verify their MacBook model and display requirements before purchase.

Important Usage Notes

• The USB-C laptop port must support Power Delivery and DisplayPort Alt Mode for full functionality.
• 8K@30Hz and 4K@120Hz require DP 1.4 with DSC support from the host laptop.
• Use a compatible DisplayPort 1.4 cable for high-refresh-rate 4K display operation.
• The 100W upstream USB-C port and 27W charging port share a combined 100W power budget.
• To achieve 100W laptop charging, the laptop must support PD 3.0 and the 27W USB-C PD port should remain unused.
• The front USB-C ports support data transfer only.
• The 27W USB-C PD port is for charging only.
• The included USB-C to USB-C cable is recommended for connecting the dock to the laptop.
• Laptops requiring more than 100W should use their original power adapter.

Included in the Box

• UGREEN Revodok Pro 14-in-1 USB-C Docking Station
• 1 × USB-C to USB-C Cable – 1m
• 1 × 140W Power Adapter
• Power Cords
• UK Plug

Ideal For

• Professional office workstations
• Hybrid working environments
• Home office setups
• Multi-monitor productivity
• Business laptops
• Corporate workstations
• Content creators
• Photographers and videographers
• Video editing workflows
• High-speed file transfers
• Video conferencing
• Cloud-based workflows
• Users requiring wired Ethernet
• Users needing multiple USB peripherals
• Windows users building a desktop-style laptop workstation

Why Choose UGREEN 85489?

The UGREEN 85489 Revodok Pro brings multiple workstation functions together through one USB-C docking solution. With 14 ports, triple 4K display support, single-display 8K capability, 100W laptop charging, 10Gbps USB connectivity, 170MB/s SD/TF card access, Gigabit Ethernet and a 140W power adapter, it provides a comprehensive expansion solution for compatible laptops.
